Usage Business

CATEGORY

Family brand EliteDisplays

FEATURES

Features Adjustable stand

DISPLAYS

Screen size 23" - 24" (58-61 cm)

Maximum resolution 1920 x 1080 (FHD)

CONNECTION AND COMMUNICATION

Interface DisplayPort, HDMI, USB port, VGA

APPEARANCE

Product color Black

SECURITY MANAGEMENT

Physical security Security lock-ready (lock is sold separately)

DIMENSIONS

Product dimensions with stand (W x D x H) 54.93 x 18.9 x 51.24 cm

Minimum dimensions (W x D x H) 54.93 x 4.96 x 33.69 cm

Dimension note (metric) Head only

DISPLAY SPECIFICATIONS

Response time 7 ms gray to gray

Tilt and swivel angle Tilt: -5 to +25°; Pivot rotation: 90°

Pixel pitch 0.265 mm

Onscreen controls Menu; Function ; Power

Input connector 1 VGA; 1 HDMI (with HDCP support); 1 DisplayPort 1.2 (with HDCP support)

View angle 178° horizontal; 178° vertical

Display type IPS w/LED backlight

Resolutions supported 1920 x 1080; 1680 x 1050; 1600 x 900; 1440 x 900; 1280 x 1024; 1280 x 800; 1280 x 720; 1024 x 768; 800 x 600; 640 x 480

Aspect ratio 16:9

Contrast ratio 1000:1 static; 5000000:1 dynamic

Display features Anti-glare; In plane switching; Language selection; LED Backlights; On-screen controls; Pivot rotation; Plug and Play; User programmable

Brightness 250 cd/m²

Resolution note (native with speed) The video card of the connected PC must be capable of supporting 1920 x 1200 at 60 Hz and include 1 VGA or 1 DisplayPort or 1 HDMI outputs to drive the monitor at the Preferred Mode.

Resolution (native) FHD (1920 x 1080 @ 60 Hz)

Display area (metric) 509.184 x 286.416 mm

Display size (diagonal) 58.4 cm (23")

CERTIFICATION AND COMPLIANCE

Certifications and compliances CE; CB; KC/KCC; NOM; ICE; TUV-S; ISO 9241-307; EAC; UL; CSA; PSB; CCC; CEL; CECP; SEPA; TCO Certified Edge; ISC; VCCI; FCC; BSMI; Vietnam MEPS; Australian-New Zealand MEPS; WEEE; Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7)

Energy efficiency ENERGY STAR® certified

WEIGHTS

Weight 3.63 kg

Weight note (metric) Head only

CONNECTIVITY AND COMMUNICATIONS

Ports 3 USB 2.0 (one upstream, two downstream)

Warranty 3 years parts and labour limited warranty.

BATTERY AND POWER

Power Input voltage: 100 to 240 VAC

Power consumption 35 W (maximum), 28 W (typical), 0.5 W (standby)

COMPATIBILITY

Accessories N6N00AA HP PC Mounting Bracket for Monitors; N2U81AA USB Graphics Adapter; NQ576AA LCD Speaker Bar; BT861AA HP Single Monitor Arm; AW664AA HP Adjustable Dual Display Stand; EM870AA Quick Release; N3R93AA HP Business PC Security Lock Kit

SERVICES

Services (Care Pack) Receive 5 years of next business day onsite repair from an HP-qualified technician for your computing device, if the issue cannot be solved remotely. For more information on Care Pack services, please visit www.hp.com/go/cpc.

What's in the box ?

• Monitor
• AC power cord
• VGA cable
• DisplayPort cable
• USB cable
• CD (includes User Guide, warranty, drivers)
